Pipe Relining Cost Sydney Explained

Pipe Location & Accessibility

Where your pipe is located has the single biggest impact on pipe relining cost. A pipe running through an accessible garden bed is straightforward to reach. A sewer pipe buried under a concrete slab, beneath a driveway, inside a wall cavity, or under a multi-storey building requires significantly more setup, equipment and time.

For pipes under slabs or driveways, accessing the pipe for the initial CCTV inspection and liner insertion may require core drilling through concrete. While this is still far less disruptive than full excavation for pipe replacement, it adds cost to the project.

Depth also matters. Deeper sewer mains require longer equipment runs and more complex access arrangements than shallow stormwater drains.

Pipe Diameter & Length

Pipe relining cost scales directly with the amount of liner material and epoxy resin required. Larger diameter pipes (100mm, 150mm, 225mm+) use more material per metre than standard 65mm or 80mm waste lines. Longer pipe runs multiply this material cost across the full distance.

A 5-metre reline of a 65mm bathroom waste pipe will cost significantly less than a 20-metre reline of a 150mm sewer main — even though the per-metre rate may be similar.

Severity & Type of Damage

The condition of the existing pipe directly affects preparation time and relining complexity.

Minor cracks and small root intrusion points are relatively straightforward — the pipe is cleaned, the liner is installed, and the job is done. However, heavily root-affected pipes require extensive hydro-jetting and sometimes robotic root cutting before the liner can be installed. Corroded cast iron pipes with significant internal scale buildup need thorough cleaning to create a proper bonding surface.

Pipes with multiple bends, diameter changes or significant joint displacement require more careful installation technique and may need additional liner sections.

The only damage pipe relining cannot address is a fully collapsed pipe where the structural form has been lost. In those cases, excavation and replacement of the collapsed section is necessary before relining can continue either side.

Number of Junctions

Every junction — where a branch pipe connects to the main line — requires robotic cutting after the liner is installed. The relining process seals over these junctions, and they must be precisely reopened from inside the relined pipe using a remote-controlled cutter.

Each junction adds 30–60 minutes of work and associated cost. A residential sewer line with connections from two bathrooms, a kitchen and a laundry may have 4–6 junctions, while a simple single-run stormwater drain may have none.

Relining Method Used

Different relining methods suit different situations, and each carries different cost profiles.

CIPP inversion relining (our primary method) is the most comprehensive option. It creates a full structural liner across the entire damaged section and is best suited for moderate to severe damage across longer runs. This method uses the most material but delivers the longest-lasting result.

Patch relining targets a specific damaged area — typically a single crack, joint break, or localised root entry point — without relining the entire pipe. This is more cost-effective when the rest of the pipe is in good condition and only a small section needs repair. See the types of pipe relining we offer.

Property Type & Working Conditions

Residential homes with straightforward access are the most common and cost-effective projects. Commercial properties, strata buildings, schools, and hospitality venues introduce additional variables:

• Working hours restrictions — some venues require after-hours or weekend work, which may affect scheduling.
• Multi-level access — high-rise strata buildings may require equipment staging across floors and coordination with building management.
• Traffic management — pipes under public footpaths or roads may require council permits and traffic control.
• Heritage restrictions — heritage-listed properties may have specific requirements around how work is carried out and what can be disturbed.

Commercial and strata pipe relining →

Emergency vs Scheduled Work

Scheduled pipe relining — where you’ve had a CCTV inspection, received a quote, and booked a convenient time — is the most cost-effective approach. You have time to compare options and plan around the work.

Emergency pipe relining — where a sewer has failed and needs urgent attention — follows the same process but may involve after-hours attendance. At Proximity Plumbing, we don’t charge a call-out fee even for urgent work, and our 24/7 availability means you won’t pay inflated emergency premiums.

Free CCTV Pipe Inspection

We attend your property at no charge ($0 call-out fee) and conduct a full CCTV inspection of your pipes. You’ll see the footage in real time and we’ll explain exactly what we find. This is the only way to accurately assess pipe condition and provide a reliable quote.

Transparent Written Quote

Based on the CCTV findings, we provide a detailed written quote that breaks down the scope of work, materials, method, and total cost. No hidden charges, no line items that appear later. The price we quote is the price you pay.

Your Decision, No Pressure

If you’re happy with the quote, we can often start the same day. If you want to compare quotes or think it over, there’s no obligation and no call-out fee for our time. We encourage you to get multiple quotes for larger projects — just make sure you’re comparing the same scope of work and product quality.
